Off Grid Energy Storage Inverter Features
- Pure sine wave output, can meet all types of load use.
- Charging current and charging voltage can be set through LCD screen to meet different specifications of voltage level of the battery.
- With multi-mode setting function, the priority level of PV, utility and battery output can be set through LCD screen.
- Wide utility input voltage range can be selected via LCD to meet different power requirements.
- With battery overcharge, over discharge, overload protection, over temperature protection, short circuit protection and other protection functions.
- With frequency auto-detection function, adapt to different grid environment.
- Plug-and-play, seamless switching under 10 ms.
Product Paramenters
| Off Grid Energy Storage Inverter |
|---|
| Mode | HYLV-3K | HYLV-5K |
| Rated Output Voltage | 230 V (208/220/230/240 Settable) |
| Rated Output Power | 3000 W (2600/2700/3000) | 5000 W (4350/4500/4800/5000) |
| Waveform | Pure sine wave output |
| Inverter Efficiency (Peak) | >90% |
| Conversion Time | 10ms (typical) |
| Rated Input Voltage | 220/230 VAC |
| Input Voltage Range | (90V-280V) ±2% |
| Rated Input Current | 13.6 A | 22.7 A |
| Frequency Range | 40-70 Hz |
| Battery Type | Lead-acid or lithium batteries |
| Maximum Charging Current | 10-130 A | 2-80 A |
| Charging Voltage Range (FV) | 26.6-27.8 V | 53.2-55.6 V |
| Charging Voltage Range (CV) | 28-29 V | 56-58 V |
| Overcharge Protection | 40 A alarm and charge off after 1 minute |
| PV Operating Voltage Range | 30-145 V | 120-500 V |
| Battery Voltage Range | 20-30 V | 40-60 V |
| MPPT Voltage Range | 30-115 V | 120-430 V |
| Maximum Output Power | 3000 W | 5000 W |
| Solar Charging Current Range (Settable) | 5-60 A | 0-80 A |
| Standards and Certification | EN/IEC 61000, EN/IEC 62040, GB/T 7260, GB/T 4943, YD/T1095, TL |
| Operating Temperature Range(°C) | -15°C to 55°C |
| Storage Temperature Range(°C) | -25°C to 60°C |
| Communication with BMS | 232 port expandable SNMP card, USB, dry node control |
| Heat Dissipation | Forced air cooling with adjustable air speed |
| Maximum Number of Parallel Machines | 9 PCS |
| Weight (kg) | 9.5 kg |
| Size (mm) | 330 W × 478 H × 115 D |
| Protection Degree | IP65 |
| Installation Style | Wall-mounted |
| Warranty | 5 years |
